Skiving hose range 1/4-2inch 6-51mm.
Can strip both the outer skin and inner skin of the hose customized mandrel required.
|
Skiving hose ID range
|
1/4-2″ 6-51mm
|
|
Motor power
|
400W
|
|
Peel tool
|
10pieces6 8 10 13 16 19 25 32 38 51
|
|
Voltage
|
380V/220V/415V/230V or customize
|
|
Peel tool
|
10pieces6 8 10 13 16 19 25 32 38 51
|
|
Package dimension
|
0.8*0.58*1.16M
|
|
Gross weight
|
80KG
|
We also manufacture high-pressure braided/spiraled rubber hoses, flexible metal hoses, drilling hoses, assemblies of super-high pressure sea-delivery oil hoses and some rubber products like silicone sheets and nylon rods.
2.Technical support any time, Our engineer cellphone:+861138214143233.Warranty time 3years, the warranty card with machine together to you.4.Supply Video to learn how to use machines.5. Door to door service, we are in charge of sending the machine to your office, after payment.hose pressing machine6.we can design machines as your draw and requirements. OEM
|
Trouble phenomena
|
Trouble reason
|
Eliminating method
|
|
Machine has not action
|
Oil tank has not been filled with oil
|
Fill oil as per requirement
|
|
Motor rotation direction is not correct
|
Regulate two phase lines
|
|
|
Electric trouble
|
Overhaul electric circuits
|
|
|
Scale is damaged
|
The scale is fastened on the oil cylinder end face by the screw
|
Regulate the scale as per the instruction to make scale to telescope freely
|
|
Conductor at scale location is connected with scale
|
Anew connect the scale conductor to make it to be insulated from scale base
|
|
|
Electric trouble
|
Overhaul electric circuits and electric elements
|
|
|
Scale conductor cutting
|
Anew connect scale
|
|
|
System pressure is excessively low
|
Adjust buckling pressure-regulating valve
|
|
|
No buckling
|
The valve core of solenoid reversal valve is seizured by foreign matters
|
Dismount solenoid reversal valve, use gasoline to clean the valve core.
|
|
Electric trouble
|
Overhaul electric circuits
|
|
|
Mould is not opened
|
Opening mould pressure is excessively low
|
Adjust opening mould pressure regulating valve
|
|
Electric trouble
|
Overhaul electric circuits
|
|
|
Lubrication is poor
|
Smear grease on the working inclined face of mould base
|
|
|
Oil leakage
|
Joint is not tightened closely
|
Tighten the oil pipe joint
|
|
Sealing washer is damaged.
|
Replace sealing washer
|
